| # Title Zabbix Agent Binaries 7.4 OpenSSL Path Scanner

=============================================================================================================================================
| # Title : Zabbix Agent Binaries 7.4 for Hardcoded OpenSSL Paths and Potential Provider Abuse |
| # Author : indoushka |
| # Tested on : windows 11 Fr(Pro) / browser : Mozilla firefox 147.0.1 (64 bits) |
| # Vendor : https://www.zabbix.com/download_agents |
=============================================================================================================================================

[+] References :

[+] Summary : This tool performs static analysis on Zabbix Agent binaries to identify hardcoded OpenSSL paths such as OPENSSLDIR, ENGINESDIR, and MODULESDIR.
It leverages strings and radare2 to extract embedded configuration paths, OpenSSL version information,
and indicators of dynamic engine or module loading (e.g., CONF_modules_load, ENGINE_by_id, dynamic_path).
Based on the extracted data, the script evaluates the potential exploitability of the binary by determining whether
the OpenSSL configuration directory may be user-writable, which could allow malicious provider or engine injection via a crafted openssl.cnf.
The output includes both human-readable analysis and structured JSON results, making the tool suitable for vulnerability research, C
VE validation, and large-scale binary auditing.

[+] POC :

#!/usr/bin/env python3

import subprocess
import sys
import re
import json
from pathlib import Path


def safe_run(cmd, timeout):
try:
proc = subprocess.run(
cmd,
capture_output=True,
text=True,
timeout=timeout
)
if proc.returncode != 0:
return ""
return proc.stdout
except Exception:
return ""


def extract_with_strings(binary_path: str) -> dict:
result = {
"binary": binary_path,
"openssl_version": None,
"openssldir": None,
"enginesdir": None,
"modulesdir": None,
"has_conf_modules_load": False,
"has_engine_by_id": False,
"has_dynamic_path": False,
}

output = safe_run(["strings", binary_path], 60)

if not output:
return result

version_match = re.search(r'OpenSSL\s+(\d+\.\d+\.\d+[^\s]*)', output)
if version_match:
result["openssl_version"] = version_match.group(1)

for key in ("OPENSSLDIR", "ENGINESDIR", "MODULESDIR"):
m = re.search(rf'{key}:\s*"([^"]+)"', output)
if m:
result[key.lower()] = m.group(1)

result["has_conf_modules_load"] = "CONF_modules_load" in output
result["has_engine_by_id"] = "ENGINE_by_id" in output
result["has_dynamic_path"] = "dynamic_path" in output

return result


def extract_with_r2(binary_path: str) -> dict:
result = {
"binary": binary_path,
"openssl_version": None,
"openssldir": None,
"openssldir_offset": None,
"enginesdir": None,
"enginesdir_offset": None,
"modulesdir": None,
"modulesdir_offset": None,
}

def parse_izz(keyword):
out = safe_run(["r2", "-q", "-c", f"izz~{keyword}", binary_path], 120)
for line in out.splitlines():
if keyword in line:
m = re.search(r'0x([0-9a-fA-F]+)\s+0x([0-9a-fA-F]+).*?(".*")', line)
if m:
return m.group(2), m.group(3)
return None, None

off, val = parse_izz("OPENSSLDIR")
if val:
result["openssldir_offset"] = f"0x{off}"
d = re.search(r'"([^"]+)"', val)
if d:
result["openssldir"] = d.group(1)

off, val = parse_izz("ENGINESDIR")
if val:
result["enginesdir_offset"] = f"0x{off}"
d = re.search(r'"([^"]+)"', val)
if d:
result["enginesdir"] = d.group(1)

off, val = parse_izz("MODULESDIR")
if val:
result["modulesdir_offset"] = f"0x{off}"
d = re.search(r'"([^"]+)"', val)
if d:
result["modulesdir"] = d.group(1)

ver = safe_run(["r2", "-q", "-c", "izz~OpenSSL", binary_path], 120)
m = re.search(r'OpenSSL\s+(\d+\.\d+\.\d+[^\s"]*)', ver)
if m:
result["openssl_version"] = m.group(1)

return result

def analyze_vulnerability(result: dict) -> dict:
vuln = {
"vulnerable": False,
"exploitability": "unknown",
"openssl_cnf_path": None,
"engine_dll_path": None,
"notes": []
}
openssldir = result.get("openssldir")
enginesdir = result.get("enginesdir")

if not openssldir:
vuln["notes"].append("OPENSSLDIR not found")
return vuln

vuln["openssl_cnf_path"] = openssldir.rstrip("/\\") + "/openssl.cnf"
vuln["engine_dll_path"] = enginesdir

path = openssldir.lower()

user_writable_hint = any(x in path for x in ("vcpkg", "users", "home", "usr\\local", "usr/local"))

if user_writable_hint and result.get("has_conf_modules_load"):
vuln["vulnerable"] = True
vuln["exploitability"] = "potentially_user_writable"
vuln["notes"].append("Writable-looking OPENSSLDIR with module loading enabled")

if result.get("has_engine_by_id"):
vuln["notes"].append("ENGINE_by_id present (engine loading supported)")

if "program files" in path:
vuln["exploitability"] = "requires_admin"
vuln["notes"].append("Protected directory (Program Files)")

return vuln


def main():
if len(sys.argv) < 2:
print(f"Usage: {sys.argv[0]} <binary> [...]")
sys.exit(1)

results = []

for binary in sys.argv[1:]:
if not Path(binary).exists():
print(f"File not found: {binary}", file=sys.stderr)
continue

r2 = extract_with_r2(binary)
s = extract_with_strings(binary)

for k in ("openssl_version", "openssldir", "enginesdir", "modulesdir"):
if not r2.get(k):
r2[k] = s.get(k)

r2.update({
"has_conf_modules_load": s["has_conf_modules_load"],
"has_engine_by_id": s["has_engine_by_id"],
"has_dynamic_path": s["has_dynamic_path"],
})

r2["vulnerability"] = analyze_vulnerability(r2)
results.append(r2)

print(json.dumps(r2, indent=2))

print("\n--- JSON Output ---")
print(json.dumps(results, indent=2))


if __name__ == "__main__":
main()
